Xtool IOBD2 MFI comes with its amazing free IOBD2 app which will help you monitor your car's engine data on your IOS or Android screens. Includes a number of performance and fuel economy gauges, data logger with maps, alerts as well as a diagnostic engine scan tool to read and clear trouble codes. It works with all OBDII compatible vehicles sold worldwide.

Connection type:

  • Bluetooth Plug & Play

Compatible Apps:

  • IOBD2 (IOS & Android)

Customisable Metrics & Alerts

  • Customise units for temperature, mileage, vehicle speed, fuel, fuel consumption, torque and horsepower.
  • Set alarm alerts for over speed, fatigue driving and water temperature
  • Set parameters of vehicle weight, fuel consumption coefficient and vehicle speed coefficient according to your needs.

Four Dashboard Options

  • [Idle mode]: Monitor engine rotational speed, water temperature, battery voltage, Air-intake temperature, instant fuel consumption (static), average fuel consumption.
  • [Cruise mode]: Monitor vehicle speed, current engine load, water temperature, Vehicle travel time, vehicle travel average speed, Continuous running mileage; instant fuel consumption (dynamic).
  • [Sport mode]: Monitor engine rotational speed, vehicle speed, water temperature.
  • [Performance mode]: Customise and monitor real-time Engine Parameters including: vehicle speed, capacity, torque & horsepower and more.

OBDII Engine Scan Tool

  • [Reads & Clear DTCs]: Read Engine diagnostic trouble codes DTC and provide both the code and its' meaning and clear them
  • [Engine Live Data]: Customise and monitor real-time engine parameters.
  • [Freeze Frame Data]:Recoded system parameters values at time when engine malfunction first occurred
  • [Readiness test]: Test and check status of engine emission control systems
  • [VIN]: Read vehicle info such as Vehicle Identification Number VIN, Calibration IDs CALID and Calibration Verification Number CVN
  • [Mode 6 & Oxygen Sensor test]: Test and check status of various on-board monitoring systems such as Oxygen Sensors, Catalyst and Evap systems

Performance Tests

  • [0 to 100km/h accelerate/decelerate test] Test acceleration/deceleration process time and distance.
  • [0 to 400m acceleration test] Test spending time from 0 to 400 meters

Car Data Logger

  • Track your driving routes, record DTC's, live data and dashboard data. Know how your car was used, where it went, avg speed and fuel consumption!
  • Share the recorded data using email or social media!

Technical Specification:

  • Dimension: 48*42*25 mm/1.89*1.66*0.99in.
  • Weight: 80g/ 2.83oz.
  • Operating Voltage: 8-19V DC
  • Operating Temperature: -20 to 50°C
  • Storage Temperature: -20 to 70°C
  • Bluetooth Standard: 2.1/2.0/1.2/1.1

Supported OBDII Protocols:

  • ISO15765-4 (CAN)
  • ISO14230-4 (KWP2000)
  • ISO9141-2
  • J1850 VPW
  • J1850 PWM

Package Includes:

  • Hardware: iOBD2 MFi BT adaptor, user manual
  • Software: iOBD2 app-free (Download manually)
SKU XTOOLMFI
Barcode # Does Not Apply
Brand Xtool
Shipping Weight 0.3000kg
Shipping Width 0.120m
Shipping Height 0.050m
Shipping Length 0.200m
Unit Of Measure ea

xtool iobd2

By: on 26 April 2019
Does what it say it does but app not the best & I couldn’t use other apps I tried.
(3)

Great product

By: on 9 August 2017
I am a dealer technician and have used this product many times since I got it and have had great success. Being in a Honda dealership I tested codes and names compared with the genuine scan tool and found to be 95 percent same Big value for money
(5)

Amazing!!

By: on 3 August 2017
I had a check engine light on my Ve commodore, I was stressed and worried about it for days, thinking the worst, so I looked for an inexpensive way to figure out what was going on before I took it the dealer and I found the Xtool iOBD2 on eBay, with an easy user interface and easy to understand functionality, it gave A list of error codes and the name of the faulty part, so I fixed it myself and it even reset the check engine light. Wow!!! I saved a lot of money, l highly recommend
(5)

Xtool auto IOBD2 OBD2 Bluetooth scan tool

By: on 10 June 2016
Haven't used the tool yet, but appears to be well made, downloaded the app for it on my iPad which shows more information than a dedicated scanner.
(4)
