The i300PRO CAN EOBD OBDII scanner is a professional OBD2 Engine code reader that helps you quickly and efficiently diagnose, read and clear engine trouble codes on almost all OBDII compatible cars. Featuring the ability to perform Mode6, Oxygen sensor tests, on-board test and component test. It also lets you view text and graph live data and perform I/M readiness quick health check. In addition, thousands of troubleshooter code tips help you save on diagnosis and repair time.

Features

• Compatibility: Works with most OBDII & CAN compliant cars, light-duty trucks, SUVs, minivans and hybrid sold wordwide
• Diagnostics: Support all the 10 OBDII test modes. Reads / clears stored & pending engine trouble codes and resets monitors. Views on-screen fault code definitions (Generic & manufacturer specific) - thousands of definitions stored within the tool.
• Live Data: Text and Graph live engine data. Reads, records, graphs & playback real-time live data streams from the engine sensors - ideal for monitoring intermittent faults
• Other Tests: View Oxygen Sensor Test, On-board Monitor Test and Component Test
• Advanced Mode 6 Functions - Non-continuously Monitored Systems test results
• Freeze-Frame: Read freeze-frame data engine conditions such as fuel trim, engine coolant temp, etc., at the time of Malfunction Indicator Lamp (MIL) was set (a snapshot of sensor values when a DTC occurred)
• I/M Readiness: Quick display of status of all tests on a single screen. Red-Yellow-Green LED lights and build-in speakers indicate emissions monitor status. They can also help catch intermittent problems or confirm repairs during the drive cycle.
• Retrieve Protocol: VIN, Cal ID and CVN identifiers from ECU (dependent on vehicle support)
• Hardware: Exquisitely designed - Ergonomic grip handle, bulging membrane switch, and gliding metal pins. A simple click from the short-cut menu to enter update mode
• Software Update: Life-time FREE software

Specification

• Display: 2.4" TFT colour Screen
• Operating Temperature: 0 - 60°C (32 to 140°F)
• Storage Temperature:20 to 70°C (-4 to 158°F)
• Power:8 to 18 V provided via vehicle
• Supported Protocols:J1859-41.6, J1850-10.4, ISO9141, KWP2000 (ISO 14230), and CAN (Control Area Network ISO 11898)
• Dimensions:125mm*80mm*24mm
• Weight: 350g

Package includes:

• i300PRO  OBDII/EOBD Code Reader
• User’s Guide
• USB PC cable for updating software
